DESIGNED AND MANUFACTURED TO EXACT SPECIFICATIONS

At Anord Mardix, we take ongoing product development seriously. We have committed to extensive R&D and testing programs as part of our business investment. The results of this approach are demonstrated in the finished product; fully installed and tested LV switchboards with a design process that perfects the top-level assembly, automatically checking for accuracy, clearance and zero clashing parts.

Our approach is to work with end users, consultants, and contractors through every step of the design, manufacturing, and installation process. Our Anord Mardix LV switchboard design is 100% Anord Mardix owned and the most technically advanced and feature rich to date. Whatever your LV switchboard requirements, please contact us and find out more about what Anord Mardix can offer your project.

KEY FEATURES

  • High short time withstand up to 150kA for 1 second (60 cycles)
  • Tested to ANSI C37.51
  • NEMA Type 1 enclosure design with optional segregation between vertical sections
  • Compartmentalized structure
  • Large cable compartment for ease of install
  • Cable entry top and bottom
  • Front access control compartments
  • Dead front metal enclosed structure for improved safety
  • Fully extendable from either side
  • Standard color ANSI 61 (other colors available)
  • Fully bolted silver plated bus system up to 5000A

MARKET LEADING BENEFITS

ROBUST – Tested at up to 150kA for 60 cycles.

MAXIMUM UPTIME – due to robust testing, ease of maintenance along with system selectivity and circuit protection as standard.

REASSURANCE FROM REPUTATION – evolution of proven IEC and UL switchgear products with decades of experience in the global market

BOLTED AND SCREW FIXED CONSTRUCTION – made from individually folded panels that are fitted and screw fixed together to form our superior Anord Mardix cubicle system with maximum rigidity

COMPARTMENTALIZED DESIGN – based on a configurable platform and designed to provide maximum flexibility. Using eight base building blocks the product can be configured to provide any combination of line-up to suit specific individual requirements

LARGE CABALLING COMPARTMENTS – Rear cabling compartments are provided in various depths up to 44in deep with optional top box. Designed to provide sufficient glanding area, cable bending space and access to the required cable terminations and optional support for cables.

SPECIFICATION

Voltage Up to 635V
System 3 Phase, 3 Wire; 3 Phase, 4 Wire
Frequency 60Hz
Main Current Ratings Up to 5000A
Neutral 100% Rated
Short Circuit Rating Up to 150kA for 1 second (60cycles)
Breakers UL 1066/ANSI C37
Feed Types Cable, Busduct, Close Coupled to Transformer, Loadbank Camlocks
Busbar Ampacity 1000A/in²
Section Widths Up to 36”
Height 91.5”
Depth 54”, 60”, 72”, 80”
Access Rear Access
Colour ANSI 61 or RAL 7035 as standard (other colours available on request
Enclosure Types 1
Enclosure Material Minimum 12 Gauge Steel
Busbar Silver plated copper
Insulation – Supports UL recognised polyester sheet moulding compound (SMC)
Insulation – Screens GP03 sheets and Lexan
